STR-HW Series Handheld Laser Welders
  • Can produce aesthetically pleasing welds of large penetration;

  • Possess Long life cycle and provide long up time;

  • Deliver good performance,including fast working speed and high efficiency;

  • Can work 24 hours/day×7 days/week;

  • Designed to be High and low temperature resistant and free of faults when welding at -20 ℃-60 ℃;

  • Easy to operate due to intelligent features;

  • Comfortable and easy to grip due to ergonomic design;

  • safe and reassuring due to 8-fold protection designs;

  • Efficient and energy-saving, green and environmentally friendly;

  • Protect the health of workers due to dust-free operation.

Product Description

Based on the self-developed "small core diameter" laser technology, the STR-HW Series handheld laser welders adopt a new dual circuit refrigerant direct cooling system and integrated structural design. These welders can provide customers with such experiences as high effectiveness, large penetration, high energy-efficiency, and high convenience. Because these welders can weld various metal materials, including aluminum, stainless steel, carbon steel, galvanized sheet, brass, etcthey find broad applications including welding building materials; welding materials used to make home electrical appliances, kitchen hardware and bathroom hardware; sheet metal processing and pipeline processing.

Product Features
Can produce aesthetically pleasing welds of large penetration;

Possess Long life cycle and provide long up time;

Deliver good performance,including fast working speed and high efficiency;

Can work 24 hours/day×7 days/week;

Designed to be High and low temperature resistant and free of faults when welding at -20 ℃-60 ℃;

Easy to operate due to intelligent features;

Comfortable and easy to grip due to ergonomic design;

safe and reassuring due to 8-fold protection designs;

Efficient and energy-saving, green and environmentally friendly;

Protect the health of workers due to dust-free operation.

Drag to see all products

STR-HW850
STR-HW200
STR-HW350
STR-HW450
STR-HW550
Product parameters

Items

Unit

STR-HW200

STR-HW350

STR-HW450

STR-HW550

STR-HW850

Rated input power supply

-

Single phase220V

Single phase220VSingle phase220VSingle phase220VThree phase380V
Input power frequency

Hz

50/60

50/60

50/60

50/60

50/60
Laser PowerW700900120015003000
Rated input power

W

3200

3800

4200

5400

10500

Welding speed

cm/min

20~200

20~200

20~200

20~200

20~250

Cooling mode

-

Dual-circuit refrigerant direct cooling

Working temperature

-30~60

-20~60

-20~60

-20~60

-30~60

Storage temperature

-40~85

--40~85

-40~85

-40~85

-40~85

Working humidity

%

0-90

0-90

0-90

0-90

0-90

Product dimensions

mm

675×310×580

675×310×580

673×310×605

673×310×605

863×410×724

Product weight

kg

38

39

43

45

70

Applicable wire diameter

mm

0.8/1.0/1.2/1.6/2.0

Number of preset process packages

pcs

16

24

30

40

50

Number of customizable process packages

pcs

20

20

20

20

20

Output mode

-

Integrated armored cable+welding torch

Armored cable lengthm5/10/15/20(Customizable)

Welding mode

-

Spot welding/Continuous spot welding/ Pulse welding/Continuous welding
